GS19 105° Standard Cabinet Hinge with 35mm Cup (16-26mm Door Thickness)

The GS19 requires a standard 35mm cup diameter with an 11.4mm cup depth. It supports a flexible door drilling distance (k) of 3-7mm and is perfectly compatible with door panel thicknesses (t) ranging from 16mm to 26mm.

Yes. Backed by the 4DAMS° technology, the GS19 hinge has successfully passed a rigorous 48-hour neutral salt spray test in our professional center. Its double anti-corrosion properties ensure the hardware remains clean, rust-free, and as good as new, even in steamy kitchen or bathroom environments.

To ensure maximum durability, ADAMS utilizes a premium three-layer process: a Heavy-Duty Cold-Rolled Steel Base for superior load capacity, a Middle Copper Plating Layer to block oxidation, and a Surface Nickel Plating Layer to isolate moisture and deliver a sleek, anti-rust finish.

Anti-rebound resistance means the hinge can withstand external reverse forces or sudden forceful pushes without bouncing back or losing its alignment. Paired with its heavy-duty one-piece solid base, this stable structure prevents door damage and ensures long-lasting reliability.

The hinge is equipped with a premium custom dampening system that supports free-hovering at various angles for effortless control. When closing, it triggers a smooth, gentle motion even at a small angle, providing silent anti-slam performance and completely eliminating kitchen cabinet clatter.

The GS19 features a specialized compact arm body that has been reduced by 20% compared to standard hinges. This minimalist design significantly saves internal lateral space, making it perfect for narrow cabinets (such as spice racks or slim larder units) without interfering with internal pull-out baskets or drawers.
