Precision engineering hidden in an outstanding metallic finish.
Engineered for multi-dimensional adjustment, heavy-duty support,
and a lifetime of silent, corrosion-resistant movement.
Category: Hinges
Cup Diameter
35 mmCup Depth
11.3 mmMax. Opening Angle
105°Door Drilling Distance(K)
3-7 mmThickness Of Door(T)
16-22 mmMaterial For Cup
Lron With Nickel PlatingMaterial For Arm
Lron With Nickel PlatingMaterial For Mounting Plate
Lron With Nickel Plating| Parameter | Description / Specification |
|---|---|
| Cup Diameter | 35 mm |
| Cup Depth | 11.3 mm |
| Max. Opening Angle | 105° |
| Door Drilling Distance (K) | 3–7 mm |
| Thickness of Door (T) | 16–22 mm |
| Material for Cup | Iron with Nickel Plating |
| Material for Arm | Iron with Nickel Plating |
| Material for Mounting Plate | Iron with Nickel Plating |
QD12E
